Kennametal KenTIP FS selection and configuration guide
Compare KenTIP FS modular drill bodies and replaceable tips as separate components of a drilling system. Identify the body, tip and application requirements before requesting a complete combination or replacement component.
Compare the configuration dimensions
For a body, check the exact diameter range, drilling depth, flute arrangement and shank style. For a tip, check the interface, diameter, geometry and published application. A matching nominal diameter is not enough to establish a compatible assembly.
Check the setup and technical references
Verify component references for the selected body and tip. Where a pairing is not established, send both material numbers to Tech Tool for confirmation. Review the applicable installation and cutting guidance before using the assembled tool.
Keep the selected tool connected to its data
Choose the required inch or metric listing and select the configuration on its product page. Read dimensions from that exact material-number row, and use the manufacturer drawing to interpret the reference symbols. Representative family images and unscaled schematics do not establish every feature of an individual configuration.
Frequently asked questions
Does every KenTIP FS tip fit every KenTIP FS body?
Do not assume that. Confirm the exact body-to-tip interface and supported size range from the manufacturer references for the selected components.
What should I include in a Kennametal KenTIP FS quote request?
Send the exact material number, quantity and required date. For application review, include workpiece material and hardness, operation, required dimensions, machine, holder and coolant details. Tech Tool confirms current pricing, availability and shipping before an order.
Explore related collections
For help narrowing a selection, contact Tech Tool with the manufacturer material number and application details.
Request a quote or selection review
